Disc springs · DIN 2093
Dimensional diagram
Definition of the columns in the table below
- De
- External diameter
- Di
- Internal diameter
- t
- Material thickness
- t′
- Reduced thickness
- lₒ
- Free height of the spring
- hₒ
- Free cone height (lₒ − t)
- F
- Nominal force at 0.75·hₒ
Dimensional diagramDefinition of the columns in the table below
Show
Hide
- De
- External diameter
- Di
- Internal diameter
- t
- Material thickness
- t′
- Reduced thickness
- lₒ
- Free height of the spring
- hₒ
- Free cone height (lₒ − t)
- F
- Nominal force at 0.75·hₒ
Reference table · DIN 2093 / DIN EN 16983 disc springs
793 results
· of 793 references in DIN 2093
| SKU | De [mm] | Di [mm] | t [mm] | t′ [mm] | lₒ [mm] | hₒ [mm] | F nom [N] | Material | Price €/unit | Stock | Quantity | Actions | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | DS-NS-51-349 | 50.0 | 25.4 | 3.0 | 4.1 | 1.1 | 11976 | 51CrV4 | €1,29 | In stock (21.139) | |||
 | DS-NS-51-303 | 40.0 | 20.4 | 2.25 | 3.15 | 0.9 | 6500 | 51CrV4 | €0,69 | In stock (1.315) | |||
 | DS-NS-51-235 | 31.5 | 16.3 | 1.75 | 2.45 | 0.7 | 3871 | 51CrV4 | €0,41 | In stock (2.728) | |||
 | DS-NS-51-177 | 23.0 | 8.2 | 1.0 | 1.7 | 1.6 | 1249 | 51CrV4 | €0,15 | In stock (24.600) | |||
 | DS-NS-51-82 | 15.0 | 8.2 | 0.8 | 1.2 | 0.4 | 982 | 51CrV4 | €0,09 | In stock (6.600) | |||
 | DS-NS-51-59 | 14.0 | 7.2 | 0.8 | 1.1 | 0.3 | 797 | 51CrV4 | €0,09 | In stock (3.600) | |||
 | DS-NS-51-10 | 8.0 | 4.2 | 0.2 | 0.45 | 0.25 | 39 | 51CrV4 | €0,07 | In stock (1.200) | |||
 | DS-NS-51-9 | 8.0 | 3.2 | 0.5 | 0.7 | 0.2 | 357 | 51CrV4 | €0,07 | In stock (800) | |||
 | DS-NS-51-583 | 160.0 | 82.0 | 4.3 | 9.9 | 5.6 | 21843 | 51CrV4 | €20,90 | In stock (40) | |||
 | DS-NS-51-449 | 80.0 | 41.0 | 5.0 | 6.7 | 1.7 | 33559 | 51CrV4 | €5,27 | In stock (2.535) | |||
 | DS-S-51-446 | 80.0 | 41.0 | 4.0 | 6.2 | 2.2 | 22874 | 51CrV4 | €4,36 | On request | |||
 | DS-NS-51-381 | 63.0 | 31.0 | 3.0 | 4.8 | 1.7 | 11772 | 51CrV4 | €1,89 | In stock (1.055) |
